NVME+LTE/5G Hat for Raspberry Pi 5

NVME+LTE/5G Hat for Raspberry Pi 5

Regular price $32.99 USD
Regular price $35.99 USD Sale price $32.99 USD
Sale Sold out

Out of stock

Estimated Shipping Date: Usually ships out in 1 to 2 business days.

Ship from: China

View full details

Product Description:

Introducing the NVMe SSD and LTE/5G Dual Hat for Raspberry Pi 5 – a revolutionary all-in-one solution to supercharge your projects. Seamlessly integrating an NVMe PCIe SSD and LTE/5G module, this Hat offers unparalleled connectivity and versatility.

Features:

  1. Dual Connectivity: Harness the power of simultaneous NVMe PCIe SSD and LTE/5G module connections for enhanced functionality and performance.

  2. SSD Compatibility: Supporting SSD sizes ranging from 2230 to 2280, with the SSD securely mounted on the underside for optimized space utilization.

  3. LTE/5G Module Integration: Compatible with 3042 or 3050 LTE/5G modules, installed on the top side for convenient access. The LTE/5G module connects to the Raspberry Pi 5's USB3.0 port via a USB-A to USB-C adapter, enabling a compact and tidy connection without the need for additional data cables. With support for a nano SIM card and a power supply switch between the Raspberry Pi GPIO/PCIe FPC connector and USB-C port, the LTE/5G module can operate independently, facilitating usage with other devices such as PCs and laptops.

  4. Official Design Specification FPC Cable: Utilizing official design specification FPC cables, ensuring compliance with the 90-ohm impedance requirement for operation at PCIe Gen3 speeds. Featuring a relative-side-contact design, these cables mitigate the risk of short circuits associated with same-side-contact PCIe FFC insertion errors.

  5. Power Supply Compliance: Meeting the 3A requirement of NVMe standards, the power supply ensures reliable and consistent performance, even under demanding workloads.

What's includes:

  • NVMe and LTE/5G Base PCB with two M.2 Slots (M-Key for SSDs, B-Key for LTE/5G modules)
  • Flat Flex Cable for PCIe connection
  • 2x M2 standoff screw nuts and M2 screws for SSD and  LTE/5G module mounting
  • M1.6 screw nut for 2280 size SSD mounting
  • 4x 22mm M2.5 standoffs
  • 8x 8mm M2.5 screws
  • 4x M2.5 standoff screw nuts
  • USB 3.0 Type-A plug to Type-C plug adapter

Note: SSDs, Antenna, 5G module, and Active cooler shown in the photos are not included.

Unlock the full potential of your Raspberry Pi 5 with the NVMe SSD and LTE/5G Dual Hat – the ultimate solution for seamless connectivity and expanded capabilities. Upgrade your projects today!
